65W Type-C PD Fast Charger Module 5V-20V Multi Protocol

65W PD3.1 USB Type-C DC-DC Fast Charging Power Delivery Module 8-32V Input

The PD65W USB Type-C fast charging module is a compact high-efficiency DC-DC power delivery board engineered for modern USB-C powered electronics. The module converts a wide DC input voltage into a negotiated USB Type-C output using intelligent communication protocols. It automatically detects the connected device and delivers the correct charging voltage, ensuring safe and optimized charging performance.

This module is particularly suitable for DIY electronics builders, robotics developers, portable power designers, solar battery users, and embedded system engineers. With support for PD3.1 (PPS), QC3.0, SCP, AFC and other fast charging standards, the board allows a standard DC source such as lithium battery packs, 12V car systems, or 24V industrial power to operate modern smartphones, tablets, and USB-C laptops.

Due to its high conversion efficiency and protection circuits, the module provides stable output with minimal heat generation. Bigyan Project users commonly integrate this module into portable lab power supplies, custom power banks, and field electronics where reliable USB-C power delivery is required.

Product Specifications

Features

• Automatic voltage negotiation with USB Type-C devices
• Supports Power Delivery PD3.1 PPS fast charging
• Wide DC input voltage range
• High conversion efficiency up to 97%
• Low ripple stable output power
• Intelligent fast charging protocol detection
• Integrated multi-layer protection circuitry
• Compact design suitable for embedded installations
• Compatible with battery powered systems
• Suitable for continuous operation

Applications / Use Cases

• DIY power bank projects
• Portable laboratory power supplies
• Solar battery charging systems
• Car USB-C laptop charger installation
• Robotics and embedded systems
• Field electronics and outdoor equipment
• Battery powered IoT devices
• Emergency backup power setups
• Custom electronics projects from Bigyan Project community

User Guide / How to Use

• Connect a DC power source within 8V–32V range to the input terminals
• Ensure input voltage is higher than desired output voltage
• Use adequate current capable wiring for high power operation
• Connect a USB Type-C cable to the module output
• Attach the target device such as phone or laptop
• The module will automatically negotiate and supply the proper voltage
• For 20V output ensure input supply exceeds 20V
• Provide ventilation for sustained 65W operation

Frequently Asked Questions (FAQs)

• Q: Can it charge a USB-C laptop?
  A: Yes, if the laptop supports USB-C Power Delivery and the input source can supply sufficient power.
• Q: Why am I not getting 20V output?
  A: The input voltage must be higher than 20V and the connected device must request 20V via PD protocol.
• Q: Can I power it from a 12V battery?
  A: Yes, it will output 5V, 9V, or 12V depending on device negotiation.
• Q: Does it automatically adjust voltage?
  A: Yes, voltage negotiation is handled automatically by the PD controller.
• Q: Is it suitable for DIY projects?
  A: Yes, it is widely used by Bigyan Project builders and electronics hobbyists.

Challenges and Considerations

• Input power source must be capable of supplying adequate current
• Heat dissipation becomes important near full 65W load
• Thin wires may cause voltage drop
• Low input voltage limits maximum charging modes
• Improper polarity connection may damage the module

Compatibility

• USB-C smartphones
• USB-C tablets
• USB-C laptops supporting Power Delivery
• PD compatible power banks
• Single board computers with USB-C input
• USB-C powered embedded devices

Future Enhancement Options

• Add enclosure for portable charger design
• Integrate cooling fan for high load operation
• Combine with lithium battery BMS system
• Integrate with solar charge controller
• Add voltage and current display meter

Benefits

• Reduces need for multiple chargers
• Converts common DC sources to modern USB-C power
• Supports most major fast charging protocols
• High efficiency reduces energy loss
• Reliable and stable charging performance
• Flexible for engineering and DIY development

Conclusion

The PD65W USB Type-C fast charging module is a practical solution for converting DC power sources into modern USB-C Power Delivery output. Its wide input range, intelligent protocol negotiation, and multiple protection features make it suitable for both professional electronics development and hobbyist projects. It is an excellent addition to portable power and embedded systems frequently built by the Bigyan Project community.
