BD140 Transistor PNP 80V 1.5A General Purpose

BD140 PNP Transistor 80V 1.5A for Amplifier and Switching

The BD140 is a widely used general-purpose PNP power transistor designed for medium power switching and amplification. With its robust capability of handling up to 80 volts and 1.5 amperes, the BD140 provides stable performance in audio amplifiers, driver circuits, and other electronic applications. This transistor is part of the BD13x series and works as the complementary pair of the BD139 NPN transistor, making it highly suitable for push-pull amplifier designs. At Bigyan Project (বিজ্ঞান প্রজেক্ট), we provide original BD140 transistors to support students, hobbyists, and professionals in building reliable science projects and DIY electronics.

Product Specifications

Features

• General-purpose PNP power transistor
• High collector current rating up to 1.5A
• Collector-emitter voltage capacity up to 80V
• Wide DC gain range of 40 to 160
• Compact TO-126 package suitable for PCB mounting
• Complementary to BD139 NPN transistor for push-pull designs
• Reliable for both audio amplification and switching applications

Applications / Use Cases

• Audio amplifier circuits
• Signal amplifier and preamplifier stages
• Switching medium power loads
• Driver circuits for other transistors or MOSFETs
• Inverter and power supply designs
• H-Bridge motor driver circuits
• Science and DIY electronics projects

User Guide / How to Use

To use the BD140 transistor, connect the emitter to the negative rail, the collector to the load, and the base through a current-limiting resistor. A base current of less than 10mA is usually sufficient to drive the transistor into saturation. Always ensure that the collector current does not exceed 1.5A and that proper heat dissipation is provided for continuous operation. In amplifier circuits, pair the BD140 with BD139 to create push-pull stages for efficient audio performance. At Bigyan Project (বিজ্ঞান প্রজেক্ট), we recommend using a heat sink for high-power applications.

Frequently Asked Questions (FAQs)

• What type of transistor is BD140? Answer: It is a general-purpose PNP power transistor.
• What is the maximum collector current of BD140? Answer: It can handle up to 1.5A continuous collector current.
• What is the complementary NPN transistor of BD140? Answer: The complementary pair is BD139.
• Can BD140 be used in audio amplifiers? Answer: Yes, it is widely used in audio amplifier stages.
• Does BD140 need a heat sink? Answer: Yes, for higher current loads a heat sink is recommended.

Challenges and Considerations

• Collector current limit of 1.5A may not support heavy loads
• Requires proper heat sinking for continuous high current use
• Maximum operating temperature is 150°C, so overheating should be avoided
• Base current should not exceed 0.5A to prevent damage

Compatibility

• Works with BD139 in complementary push-pull amplifier designs
• Can be replaced with BD136, BD138, or D882 in some circuits
• Compatible with audio and driver circuits requiring medium power PNP transistors

Future Enhancement Options

• Using with Darlington pairs for higher current gain
• Integration in H-Bridge motor driver designs
• Combining with MOSFETs for efficient hybrid circuits
• Using heat sinks and cooling fans for extended performance

Benefits

• Reliable medium power switching and amplification
• Simple to use in educational and DIY projects
• Cost-effective transistor with wide availability
• Supports a variety of amplifier and driver applications
• Provided by Bigyan Project (বিজ্ঞান প্রজেক্ট) with quality assurance

Conclusion

The BD140 transistor is a versatile and dependable PNP power transistor suitable for audio, driver, and switching circuits. With its 80V voltage rating and 1.5A current capacity, it is one of the most popular choices for students, hobbyists, and professionals. At Bigyan Project (বিজ্ঞান প্রজেক্ট), we ensure that every BD140 transistor meets high quality standards to help you build stable and efficient electronic projects. Whether you are designing an amplifier, a driver circuit, or a science project, the BD140 will deliver consistent performance and reliability.
