Micro USB 2-Pin Female Connector Power Jack

High-Quality Micro USB 2-Pin Female Connector for Power & DIY Solutions

Introducing the premium Micro USB 2-Pin Female Connector, meticulously designed for reliable power delivery in mobile charging, electronics repair, and innovative DIY projects. Sourced by Bigyan Project, this connector serves as a robust solution for powering your devices and circuits. Its B-type, 2-pin configuration is specifically tailored for power input/output, making it an indispensable component for hobbyists and professionals alike. Crafted with a durable stainless steel housing and high-conductivity brass terminals, this connector ensures longevity and stable performance. Whether you're replacing a worn-out port or building a custom power setup, this Micro USB jack offers a convenient and dependable connection. Its compact size and versatile mounting options (DIP and SMT) make integration seamless. Experience the quality and reliability that বিজ্ঞান প্রজেক্ট brings to your electronic endeavors.

Product Specifications

Key Features

• Compact and lightweight design for easy integration.
• Durable stainless steel housing ensures long-term reliability.
• Nickel-plated finish for enhanced corrosion resistance and conductivity.
• High-quality brass terminals for stable electrical connections.
• Supports 1.0A current and 30V AC voltage, suitable for low-power applications.
• Wide operating temperature range from -30°C to +80°C.
• Available in both Through-Hole (DIP) and Surface Mount (SMT) versions.
• Ideal for mobile phone charging ports and power supply repairs.
• Provides a secure and stable power connection for DIY electronics projects.

Applications / Use Cases

• Mobile phone charging port replacement or upgrade.
• Power input for small electronic devices and gadgets.
• Custom power supply solutions for Arduino, Raspberry Pi, and other microcontrollers.
• Repairing damaged USB ports on power banks, speakers, and other accessories.
• Building custom charging docks or adapters.
• Integrating power connectors into project enclosures.
• Educational electronics kits and STEM projects.
• Low-power data transfer applications where only power pins are utilized.

User Guide / How to Use

• For DIP Mounting: Insert the pins through the corresponding holes on your Printed Circuit Board (PCB). Solder the pins securely to the copper pads for a robust connection. Ensure correct orientation before soldering.
• For SMT Mounting: Place the connector onto the designated SMT pads on your PCB. Use appropriate soldering techniques for surface mount components, such as reflow soldering or careful hand soldering.
• Wiring: Typically, the two pins on a 2-pin Micro USB connector correspond to VCC (+5V) and GND (Ground). Ensure correct polarity when connecting to your power source or device to prevent damage.
• Testing: After soldering, visually inspect the connections for any bridges or cold joints. Test continuity and polarity with a multimeter before applying power.

Frequently Asked Questions (FAQs)

• Q: What is the primary use of this Micro USB 2-Pin connector?
  A: Its primary use is for providing a power connection, ideal for charging mobile devices, powering small electronics, and DIY projects.
• Q: Can this connector be used for data transfer?
  A: No, this is a 2-pin power-only connector. Micro USB typically has 4 or 5 pins for data and power; this version is simplified for power applications only.
• Q: What is the difference between DIP and SMT versions?
  A: DIP (Dual In-line Package) connectors are through-hole, meaning their pins go through holes in the PCB. SMT (Surface Mount Technology) connectors are designed to be soldered directly onto the surface of the PCB.
• Q: What is the maximum current this connector can handle?
  A: It is rated for a maximum current of 1.0A.
• Q: Is this connector suitable for high-power applications?
  A: No, it is designed for low-power applications, with a maximum rating of 1.0A.
• Q: Where can I find this component from Bigyan Project?
  A: You can find this and other electronic components from বিজ্ঞান প্রজেক্ট on our online store or through authorized resellers.

Challenges and Considerations

• Limited to power only; not suitable for data transmission.
• The 1.0A current rating restricts its use to low-power devices.
• Careful soldering is required, especially for SMT versions, to ensure reliable connections.
• Incorrect polarity during wiring can damage connected devices.
• Requires a compatible Micro USB cable for power input.

Compatibility

• Compatible with standard Micro USB power cables (ensure they are wired correctly for power).
• Can be used with various development boards (Arduino, ESP32, Raspberry Pi Zero) for power input when adapted.
• Suitable for use with portable chargers, battery packs, and other low-voltage power sources.
• Works with a wide range of electronic components and modules requiring a 5V power input.

Future Enhancement Options

• Integrating this connector into custom 3D-printed project enclosures for a professional finish.
• Using it as part of a modular power system for quick device connections and disconnections.
• Combining it with voltage regulators to create versatile power adapter boards.
• Developing a breakout board that converts standard Micro USB 2-pin to screw terminals or JST connectors.

Benefits

• Cost-effective solution for power connectivity in projects.
• Provides a standardized power input method, simplifying design.
• Durable construction ensures a long service life.
• Versatile mounting options (DIP/SMT) cater to different PCB designs.
• Enables easy repair and replacement of power ports.
• Compact form factor saves valuable space on PCBs.
• Reliable performance for stable power delivery.
• Empowers makers and DIY enthusiasts with essential electronic components.

Conclusion

The Micro USB 2-Pin Female Connector is a vital component for anyone involved in electronics projects, repairs, or custom power solutions. Its robust build, ease of use, and specific power-focused design make it a go-to choice for reliable connectivity. Whether you are a seasoned engineer or a budding hobbyist, this connector from Bigyan Project offers the quality and functionality you need to bring your electronic ideas to life. Trust বিজ্ঞান প্রজেক্ট for your essential electronic components.
