NRF24L01 8Pin Socket Adapter Board with 3.3V Regulator

NRF24L01 Wireless Module 8 Pin Socket Adapter Board with 3.3V Regulator

The NRF24L01 Wireless Module 8 Pin Socket Adapter Board is a compact and reliable solution designed to power and stabilize your NRF24L01 or NRF24L01+ transceiver modules. Built with an on-board AMS1117-3.3 voltage regulator and a mini 360 DC-DC buck converter, this adapter board provides consistent 3.3V output from a wide input voltage range. Whether you are a hobbyist working on Arduino projects, a student building a robot car, or an engineer developing wireless communication systems, this socket adapter board ensures efficient performance, easy integration, and long-term stability. Offered by Bigyan Project (বিজ্ঞান প্রজেক্ট), this board is an ideal choice for makers and innovators who want to enhance their wireless module projects.

Product Specifications

Features

• Stable 3.3V regulated output for NRF24L01 modules
• On-board AMS1117-3.3 chip ensures reliable power regulation
• Mini 360 DC-DC buck converter supports wide input voltage range
• Compact and lightweight design saves space in circuits
• Provides protection against unstable voltage fluctuations
• Optimized for use with Arduino, Raspberry Pi, and microcontroller boards
• Easy to integrate with existing electronic projects
• Designed for long-term durability and consistent performance

Applications / Use Cases

• Wireless data transmission in Arduino-based projects
• Smart home automation systems with NRF24L01 modules
• Remote control of robot cars and robotic systems
• IoT device communication requiring 2.4GHz wireless modules
• Educational electronics projects in schools and universities
• Prototyping and testing of wireless communication setups

User Guide / How to Use

Using the NRF24L01 Socket Adapter Board is simple and beginner-friendly. Connect the adapter board to your NRF24L01 wireless module by aligning the 8-pin socket. Supply the board with a DC input voltage between 5V and 12V. The built-in regulator automatically steps down the voltage to a stable 3.3V output, which powers the NRF24L01 module safely. Finally, connect the adapter to your Arduino, Raspberry Pi, or microcontroller via the SPI interface to enable wireless communication. The board requires no additional setup, making it convenient for both beginners and advanced users.

Frequently Asked Questions (FAQs)

• Q: Can I directly power the NRF24L01 with 5V?
  A: No, the NRF24L01 requires 3.3V. This adapter board regulates the voltage to ensure safe operation.
• Q: Is this adapter compatible with NRF24L01+ modules?
  A: Yes, it supports both NRF24L01 and NRF24L01+ versions.
• Q: What is the recommended input voltage?
  A: The adapter works best with a 5V to 12V DC input supply.
• Q: Do I need additional components for my Arduino project?
  A: No, the adapter is designed to plug directly into your setup without extra parts.
• Q: Can it be used with Raspberry Pi?
  A: Yes, it is fully compatible with Raspberry Pi as long as the SPI interface is used.
• Q: Where can I buy this product?
  A: You can get it from Bigyan Project (বিজ্ঞান প্রজেক্ট), a trusted source for electronics and science project components.

Challenges and Considerations

• Ensure input voltage does not exceed 12V for safe operation
• Correct pin alignment is essential to avoid damage to the module
• Wireless range depends on environmental interference and antenna quality
• Stable power supply is recommended for optimal data transmission

Compatibility

• Compatible with NRF24L01 and NRF24L01+ modules
• Works with Arduino UNO, Nano, Mega, and other variants
• Supports Raspberry Pi boards with SPI communication
• Suitable for ESP8266, ESP32, and other microcontrollers
• Can be used in IoT, robotics, and home automation setups

Future Enhancement Options

• Adding an external antenna for extended wireless range
• Integrating with advanced IoT gateways
• Combining with sensors for smart automation systems
• Using in mesh networking projects for broader connectivity

Benefits

• Provides a safe and stable 3.3V output for NRF24L01 modules
• Simplifies project wiring by reducing voltage concerns
• Compact design fits easily into small enclosures
• Improves performance of wireless communication systems
• Enhances reliability of Arduino and robotics projects
• Backed by Bigyan Project (বিজ্ঞান প্রজেক্ট) for quality assurance

Conclusion

The NRF24L01 Socket Adapter Board with a built-in 3.3V regulator is an essential accessory for anyone working with NRF24L01 wireless modules. Its reliable design ensures safe power delivery, stable performance, and easy integration with Arduino, Raspberry Pi, and IoT devices. From students building science projects to engineers designing wireless systems, this adapter board is a practical solution for enhancing communication projects. Available at Bigyan Project (বিজ্ঞান প্রজেক্ট), it provides makers with the confidence to create, experiment, and innovate.
