Emax XA2212 1400KV RC Brushless Motor

Emax XA2212 1400KV 2-3S High-Speed Brushless Motor for RC FPV Plane & Flying Wing

Unlock high-speed performance for your RC aircraft with the Emax XA2212 1400KV Brushless Motor. This motor is a powerhouse from the renowned Emax XA2212 series, specifically engineered for RC hobbyists who demand speed and reliability. With its 1400KV rating, it is the perfect choice for pusher-style FPV planes and fast-flying wings, providing an impressive amount of thrust when paired with a 2-3S LiPo battery. Whether you are building a new high-speed project or upgrading an existing one, this Emax motor offers a fantastic blend of quality, performance, and value, now available in Bangladesh from Bigyan Project (বিজ্ঞান প্রজেক্ট).

Product Specifications

Features

• High-Speed 1400KV Rating: Optimized for velocity, making it ideal for fast RC planes and FPV wings.
• Versatile Voltage Range: Fully compatible with both 2S and 3S LiPo batteries, allowing you to tune performance.
• Reliable Emax Quality: Built with high-quality bearings and magnets for smooth operation and a long lifespan.
• Standard Mounting: The 2212 stator size and mounting pattern make it a drop-in replacement for many common RC aircraft.
• Efficient Design: Balances power consumption with thrust output for longer, more exciting flights.

Applications / Use Cases

• Pusher-Prop FPV Planes (e.g., ZOHD Dart, SonicModell AR Wing)
• High-Speed Flying Wings
• Fast "Pusher Jet" Style Foam Planes
• Lightweight RC Sport Airplanes requiring high RPM
• DIY RC aircraft projects focused on speed

User Guide / How to Use

1. Mounting: Securely mount the motor to your aircraft's firewall or motor mount using the appropriate length screws. Ensure screws do not touch the motor windings inside.
2. ESC Connection: Connect the three motor wires to your brushless Electronic Speed Controller (ESC). The order does not matter for initial connection. If the motor spins in the wrong direction, simply swap any two of the three wires.
3. Propeller Installation: Attach a compatible propeller (e.g., 8040, 8060) to the 3mm shaft using the included prop adapter. Ensure the propeller is balanced and secured tightly.
4. Battery: Use a 2S or 3S LiPo battery that can handle the current draw. A 3S battery will provide maximum speed and performance.
5. Testing: Always perform a safety check without the propeller first. Then, with the propeller attached, test at a low throttle to confirm correct operation before your first flight.

Frequently Asked Questions (FAQs)

• Q: What is the best propeller for this Emax XA2212 1400KV motor?
  A: For a 3S LiPo battery, an 8x4 (8040) or 8x6 (8060) propeller is a very popular and efficient choice for high speed. For 2S, you can use a larger prop like a 9x6 (9060) or 10x4.7 (1047).
• Q: What size ESC (Electronic Speed Controller) should I use?
  A: A 30A ESC is a safe and recommended choice for this motor to handle the current draw, especially when using a 3S battery and an aggressive propeller.
• Q: Can I use this 1400KV motor for a quadcopter or multirotor?
  A: No, this 1400KV version is not recommended for multirotors. It is designed for high-speed fixed-wing planes. For multirotors, the 980KV version of the XA2212 is a much better choice.
• Q: Is this motor available from Bigyan Project?
  A: Yes, this Emax XA2212 1400KV brushless motor is available from our shop, বিজ্ঞান প্রজেক্ট (Bigyan Project), ready for your next RC build.

Challenges and Considerations

• Propeller Selection: Using a propeller that is too large or has too much pitch (e.g., 10x47 on 3S) can over-prop the motor, leading to overheating and potential damage to the motor or ESC.
• Current Draw: This high-KV motor will draw significant current at full throttle. Ensure your LiPo battery has a high enough 'C' rating to supply the power without sagging.
• Cooling: Ensure your aircraft design allows for adequate airflow over the motor to keep it cool during high-speed flights.

Compatibility

• ESCs: Compatible with most major brands of 20A-40A brushless ESCs.
• Batteries: Designed for 2S (7.4V) and 3S (11.1V) LiPo battery packs.
• Propellers: Fits propellers with a standard 3mm shaft adapter or custom adapters for that size.
• Mounts: Standard 16x19mm mounting hole pattern common to 2212-size motors.

Future Enhancement Options

• ESC Upgrade: Pair this motor with a high-quality ESC running BLHeli_32 or AM32 firmware for smoother throttle response and better efficiency.
• Battery Upgrade: Using a high C-rating Graphene or LiHV battery can provide a noticeable boost in punch and top-end speed.
• Propeller Tuning: Experimenting with different propeller materials (e.g., carbon fiber) or pitch (e.g., 8x6 vs 8x4) can fine-tune the aircraft's speed and handling.

Benefits

• High-Speed Flight: The primary benefit is achieving high speeds with pusher prop planes and wings.
• Excellent Value: Offers performance comparable to more expensive motors, making it a budget-friendly choice.
• Proven Reliability: Emax is a trusted brand in the RC community, known for producing durable and consistent motors.
• Wide Availability: As a popular model, finding support and compatible parts is easy, especially from Bigyan Project.

Conclusion

The Emax XA2212 1400KV Brushless Motor is a top-tier choice for any RC hobbyist in Bangladesh looking to build a fast and agile fixed-wing aircraft. Its combination of speed, reliability, and 2-3S flexibility makes it a versatile workhorse for FPV and sport flying. For a powerful and dependable motor for your next high-speed build, look no further. Get your genuine Emax motor from Bigyan Project (বিজ্ঞান প্রজেক্ট) and start building your dream plane today.
